Product details
2023 Hitachi X-MET8000 Handheld XRF Analyzer
Advanced Portable XRF Solution for Material Identification
Introduction to Hitachi X-MET8000
The 2023 Hitachi X-MET8000 Handheld XRF Analyzer is a high-performance portable device designed for fast and reliable elemental analysis. Built for demanding industrial environments, the X-MET8000 delivers accurate results for material identification, quality control, and compliance testing.
What Is a Handheld XRF Analyzer
A handheld XRF analyzer uses X-ray fluorescence technology to determine the elemental composition of materials. This method enables non-destructive testing, making it ideal for on-site analysis without damaging samples.
X-Ray Fluorescence Technology
XRF technology works by measuring secondary X-rays emitted from a material when excited by a primary X-ray source, allowing precise identification of elements.
Non-Destructive Testing Method
The X-MET8000 analyzes materials without altering their structure, supporting safe and efficient field inspections.
Key Features of Hitachi X-MET8000
High-Speed Elemental Analysis
The analyzer provides rapid results, enabling efficient decision-making in field and industrial operations.
Smart and Intuitive Interface
A modern touchscreen interface allows easy operation and clear visualization of analysis results.
Rugged and Portable Design
Engineered for durability, the device is suitable for harsh environments such as factories, scrap yards, and outdoor sites.
Industrial Applications
Scrap Metal Recycling
Supports fast alloy identification and sorting to improve recycling efficiency.
Manufacturing Quality Control
Ensures material compliance and correct alloy usage during production processes.
Positive Material Identification
Used for PMI applications in maintenance, inspection, and safety-critical industries.
Performance and Reliability
Accurate Element Detection
Advanced detector technology delivers reliable elemental composition data across a wide range of alloys.
Consistent Field Results
Designed to maintain measurement stability in varying environmental conditions.
Workflow Efficiency
Easy Operation in the Field
Minimal training is required to begin testing, reducing setup time and operational complexity.
Data Storage and Reporting
Measurement results can be stored and exported for reporting, traceability, and audit purposes.
Benefits of Using Hitachi X-MET8000
Increased Productivity
Fast analysis reduces inspection time and improves overall workflow efficiency.
Reduced Operational Costs
On-site testing eliminates the need for laboratory analysis in many applications.
Trusted Hitachi Technology
Developed by Hitachi, a globally recognized leader in analytical and industrial instrumentation.
Ideal Users
Industrial Inspectors and Technicians
Designed for professionals who require reliable material analysis in the field.
Recycling and Processing Facilities
Supports accurate material classification and sorting operations.
Specifications – Hitachi X-MET8000 Handheld XRF Analyzer
General Information
Product name Hitachi X-MET8000 Handheld XRF Analyzer
Manufacturer Hitachi High-Tech Analytical Science
Analyzer type Portable handheld X ray fluorescence analyzer
Technology Energy dispersive XRF spectroscopy
Year release 2023
Physical Specifications
Weight approximately 1.5 kg including battery
Dimensions approximately 93 mm width 210 mm length 272 mm height
Housing rugged industrial design
Ingress protection IP54 dust and splash resistant
Drop resistance compliant with MIL-STD-810G standards
Operating orientation handheld one hand operation
XRF Excitation Source
X ray tube type Miniature high performance X ray tube
Maximum tube voltage up to 40 kV depending on configuration
Maximum tube power approximately 4 W
Beam spot size standard approximately 10 mm optional small spot collimator around 3 mm
Primary beam filters automatic multi position filter system on Optimum and Expert models
Detector System
Detector type High resolution silicon drift detector SDD
Energy resolution optimized for alloy and trace element detection
Cooling system electronic cooling no liquid nitrogen required
Elemental Analysis Capability
Element range Magnesium Mg to Uranium U depending on model and application
Simultaneous element detection up to approximately 40 elements
Alloy grade library extensive preinstalled alloy libraries
Calibration method factory calibrated fundamental parameters with optional custom calibration
Performance
Typical analysis time 1 to 5 seconds for alloy identification
Repeatability high precision for PMI and QC applications
Accuracy optimized for industrial alloy sorting and compliance testing
Display and User Interface
Display type 4.3 inch color touchscreen
Display resolution approximately 480 x 800 pixels
User interface icon driven graphical interface
Language support multiple international languages
Data Handling and Storage
Internal memory capacity up to approximately 100000 test results
Data types stored spectra chemistry results time date and user ID
Export formats CSV PDF and proprietary formats
Data transfer USB WiFi and Bluetooth connectivity
Battery and Power
Battery type rechargeable lithium ion battery
Typical battery life up to 10 to 12 hours continuous operation
Charging method external AC charger
Hot swap battery support available on certain models
Environmental Operating Conditions
Operating temperature range approximately minus 10 C to plus 50 C
Storage temperature range approximately minus 20 C to plus 60 C
Maximum sample temperature up to 100 C standard higher with optional heat shield
Safety Features
Radiation safety integrated shielding and interlock system
User protection safety nose and trigger lock
Compliance international radiation safety standards
Standard Applications
Positive material identification PMI
Scrap metal sorting and recycling
Manufacturing quality control
Precious metal analysis
Mining and geological screening
Environmental testing depending on configuration
Standard Package Contents
Handheld XRF analyzer unit
Rechargeable lithium ion battery
Battery charger and power adapter
Calibration check reference sample
USB cable and documentation
Protective carrying case
