Canfield Vectra XT 3D Imaging System for Advanced Aesthetic Visualization

Introduction to Canfield Vectra XT 3D

The Canfield Vectra XT 3D is an advanced three dimensional imaging system designed for medical aesthetics plastic surgery and dermatology clinics. This technology allows practitioners to capture highly accurate 3D images that support treatment planning patient education and outcome visualization.

What Is Canfield Vectra XT 3D Technology

High Precision 3D Imaging

Vectra XT 3D captures detailed three dimensional images of the human body and face providing realistic visual representation for clinical evaluation.

Advanced Surface Mapping

The system analyzes surface contours volume and symmetry to assist clinicians in making data driven aesthetic decisions.

Realistic Treatment Simulation

Vectra XT 3D enables visual simulations that help patients understand potential treatment outcomes before procedures.

Key Benefits of Canfield Vectra XT 3D

Enhanced Patient Communication

Three dimensional visualization improves patient understanding confidence and satisfaction.

Accurate Treatment Planning

High resolution imaging supports precise planning for aesthetic and reconstructive procedures.

Objective Measurement and Analysis

The system provides quantitative measurements for volume distance symmetry and shape analysis.

Applications of Canfield Vectra XT 3D

Aesthetic Medicine and Cosmetic Surgery

Ideal for facial analysis body contouring breast procedures and injectable treatments.

Plastic and Reconstructive Surgery

Supports pre operative planning and post treatment comparison.

Dermatology and Skin Assessment

Used to document skin conditions scars and surface changes over time.

How Canfield Vectra XT 3D Works

Rapid Image Capture

Multiple cameras capture synchronized images in a single moment ensuring accuracy and consistency.

Advanced Software Processing

Captured images are processed into a detailed 3D model using intelligent imaging algorithms.

Data Storage and Comparison

Images can be stored and compared over time to track treatment progress and results.

Who Should Use Canfield Vectra XT 3D

Ideal Clinics and Practices

Plastic surgery clinics
Aesthetic medicine centers
Dermatology practices
Medical spas with advanced consultation services

Suitable Patient Types

Patients seeking aesthetic treatments
Patients requiring visual explanation of procedures
Patients interested in outcome simulation

Why Choose Canfield Vectra XT 3D

Trusted Imaging Technology

Canfield is recognized globally for clinical imaging and medical photography innovation.

High Level Accuracy and Consistency

Vectra XT 3D delivers reproducible results suitable for clinical documentation.

Professional Consultation Tool

The system enhances clinic credibility and improves conversion during consultations.

Canfield Vectra XT 3D for Clinical Growth

Improve Consultation Experience

Visual simulations increase patient engagement and decision confidence.

Increase Treatment Acceptance

Clear visualization helps patients commit to recommended procedures.

Strengthen Clinical Documentation

Consistent imaging supports medical records research and long term follow up.

Specifications – Canfield Vectra XT 3D Imaging System

System Overview

Device Name Canfield Vectra XT 3D Imaging System
Manufacturer Canfield Scientific
Application 3D imaging for face breast and body scans for aesthetic planning and patient visualization
Technology Stereophotogrammetry 3D capture for high resolution surface imaging

Imaging Performance

Capture Technology Proprietary stereophotogrammetry imaging system
Geometry Resolution Face capture approximately 1.2 mm triangle edge length
Capture Time Fast capture at approximately 3.5 milliseconds making system less sensitive to patient movement
Intelligent Flash System On-board modular intelligent flash units for consistent lighting and color balance
Proprietary Lighting Proprietary lighting design automatically adjusts for optimal face breast and body imaging

Physical and Hardware Features

Design Compact imaging module with low profile projection less than 17 inches from wall
Motorized Lift Floor stand with motorized height adjustment for accurate patient positioning
System Includes VECTRA XT imaging device Dell PC monitor keyboard mouse and required cabling (configuration may vary by purchase)
Display Interface High resolution flat panel display included or connected via workstation

Software Capabilities

Primary Software VECTRA 3D Capture and VECTRA 3D Analysis modules
Visualization Tools Face Sculptor Breast Sculptor Body Sculptor modules for outcome simulations
RBX Image Processing Proprietary RBX technology for enhanced visualization of skin color components
Mirror Software Integration Mirror PhotoFile and Mirror PhotoTools for additional 2D and 3D workflow support
ViewMyConsult Patient Portal Optional ViewMyConsult secure portal for patient image access and sharing

Measurement and Analysis Tools

Automated Measurements System provides automated linear area and volume measurements
Circumferential Measurements 360° imaging with automatic circumference measurements for full body analysis
Markerless Tracking Dynamic assessment of skin surface changes through markerless tracking
Volume Difference One click automatic volume difference mapping for before and after comparison
Contour Visualization Gray mode available for contour revelation during analysis

System Requirements and Power

Power Supply Dual voltage support 110-120 V AC 50/60 Hz or 220-240 V AC 50/60 Hz 5 A
Capture Workstation Provided and configured by Canfield Scientific specific to the imaging system
Optional Consultation Computer Recommended Operating System Windows 11 Professional 64-bit or Windows 10 Professional 64-bit
Processor Intel Core i7 recommended for consultation processing
Memory Requirements Minimum 16 GB RAM or greater recommended
Graphics Dedicated graphics card with at least 4 GB memory recommended
Display Requirements 1920 x 1080 resolution minimum and support for higher resolution displays
Connectivity Required USB ports and wired network connectivity for image storage and data management

Imaging Options and Customization

Face Imaging High resolution 3D facial capture suitable for aesthetic facial assessment and surgical planning
Breast Imaging 3D breast capture with Breast Sculptor simulation tools including implant visualization and asymmetry analysis
Body Imaging Full body 3D wraparound imaging with automatic stitching of front and back views
Skin Analysis Optional skin analysis sculptor module for detailed surface assessment

Clinical and Consultation Use

Patient Education Tools 3D visualization tools to educate patients on possible outcomes
Treatment Simulation Compare multiple scenarios side by side or overlay simulated outcomes with original capture
HIPAA Compliance Designed to support integration into HIPAA compliant practices

Optional Accessories and Add-Ons

VECTRA Modules Additional sculpting and analysis modules may be purchased separately depending on clinical needs
ViewMyConsult Portal Optional remote access and secure patient image sharing platform

Software Features:

– Automated Measurements
– Circumferential Measurements
– Gray Mode for revealing contours
– RBX Technology for visualization of pigment related skin conditions
– Markerless Tracking for dynamic assessment of skin surface changes
– One Click Volume Difference Measurement
– Simulated Contouring
– Dorsal Adjustment
– Face, Body and Breast Sculpting

Hardware Features:

– 3.5 ms capture time
– 1.2 mm geometry resolution
– 17\’ low profile off the wall footprint

Includes:

– VECTRA XT Imaging Device
– Dell PC
– Monitor
– Keyboard
– Mouse
– Cables

VECTRA Software

– Face Sculptor
– Breast Sculptor
– Body Sculptor
– RBX Image Processing
– VECTRA 3D Analysis

Mirror Software

– PhotoFile
– PhotoTools

Warranty Information
2 Years
