Product details
Creaform GoSCAN SPARK 3D Scanner
Overview of Creaform GoSCAN SPARK
The Creaform GoSCAN SPARK is a professional handheld 3D scanner designed for fast, intuitive, and accurate data capture. Engineered for ease of use, this scanner delivers high-quality 3D data without complex setup, making it ideal for design, engineering, and digital documentation tasks.
With its lightweight design and reliable structured light technology, GoSCAN SPARK supports efficient 3D scanning for a wide range of applications.
What Is Creaform GoSCAN SPARK Used For
Product Design and Development
The scanner enables designers to quickly digitize physical objects and integrate them into digital workflows for product development and prototyping.
Reverse Engineering
GoSCAN SPARK captures detailed geometry, allowing users to recreate accurate CAD models from existing parts.
3D Documentation and Visualization
The scanner is widely used for creating accurate 3D models for visualization, presentation, and digital archiving.
Key Features of Creaform GoSCAN SPARK
Structured Light 3D Scanning Technology
GoSCAN SPARK uses advanced structured light technology to capture accurate geometry while remaining easy to operate.
Portable and Ergonomic Design
The handheld form factor allows comfortable scanning from multiple angles, improving accessibility and scanning efficiency.
Real-Time Data Acquisition
The scanner provides immediate visual feedback, enabling users to monitor data quality during the scanning process.
Fast Setup and Operation
Minimal calibration and intuitive software make GoSCAN SPARK suitable for both beginners and professionals.
Benefits of Using Creaform GoSCAN SPARK
Easy-to-Use Scanning Solution
The scanner is designed for simplicity, reducing the learning curve and enabling quick adoption.
Efficient Workflow Integration
GoSCAN SPARK integrates smoothly with Creaform software solutions for processing and exporting scan data.
Reliable Scanning Results
Consistent data capture ensures dependable results across various object types and applications.
Creaform GoSCAN SPARK in Professional Industries
Industrial Design and Engineering
Used to digitize components and support design iteration and validation.
Manufacturing Support
Assists in part analysis, tooling design, and production planning.
Education and Research
Provides a practical 3D scanning solution for teaching, research, and applied projects.
Why Choose Creaform GoSCAN SPARK
Balanced Performance and Usability
GoSCAN SPARK offers a strong balance between accuracy, speed, and ease of use.
Portable 3D Scanning Solution
Its lightweight design allows scanning in studios, workshops, or on-site environments.
Trusted Creaform Technology
Backed by Creaform’s experience in professional 3D measurement solutions.
Technical Specifications
General Information
| Item | Specification |
|---|---|
| Product Name | Creaform GoSCAN SPARK |
| Scanner Type | Handheld Structured Light 3D Scanner |
| Technology | White Light / Structured Light |
| Accuracy Grade | Professional-grade |
| Manufacturer | Creaform (AMETEK, Inc.) |
| Target Applications | Product design, reverse engineering, 3D documentation |
Accuracy & Resolution
| Parameter | Specification |
|---|---|
| Maximum Accuracy | Up to 0.050 mm |
| Volumetric Accuracy | 0.050 mm + 0.100 mm/m |
| Resolution (Point Spacing) | As fine as 0.100 mm |
| Measurement Repeatability | High repeatability for design workflows |
| Calibration Method | Factory calibrated |
Scanning Performance
| Feature | Specification |
|---|---|
| Scanning Speed | Up to 1,500,000 measurements/second |
| Real-Time Visualization | Yes |
| Dynamic Referencing | Not required |
| Field of View | Up to 390 × 390 mm |
| Data Capture Mode | Continuous handheld scanning |
Light Projection System
| Feature | Specification |
|---|---|
| Light Source | White light LEDs |
| Light Class | Eye-safe |
| Surface Compatibility | Optimized for matte and textured surfaces |
| Reflective Surface Handling | May require spray for best results |
Object Size Capability
| Parameter | Specification |
|---|---|
| Minimum Object Size | ~50 mm |
| Recommended Object Size | 50 mm – 3 m |
| Large Object Scanning | Supported via continuous scanning |
Tracking & Alignment
| Feature | Specification |
|---|---|
| Tracking Method | Geometry-based tracking |
| Target Requirement | Not required |
| Automatic Alignment | Yes |
| User Interaction | Minimal manual alignment |
Color & Texture Capture
| Feature | Specification |
|---|---|
| Color Capture | Yes |
| Texture Resolution | High-quality color texture |
| Visual Output | Realistic colored 3D meshes |
Software & Data Processing
| Feature | Specification |
|---|---|
| Scanning Software | VXelements |
| Post-Processing Tools | Cleaning, meshing, alignment |
| Operating System | Windows 10 / Windows 11 (64-bit) |
| Output Formats | STL, OBJ, PLY |
| CAD Compatibility | SolidWorks, CATIA, Fusion 360, Geomagic |
Connectivity & Interface
| Feature | Specification |
|---|---|
| Connection Type | USB 3.0 |
| Data Transfer | Real-time via PC |
| Control Interface | Software-based |
Power Requirements
| Feature | Specification |
|---|---|
| Power Source | USB-powered |
| External Power Supply | Supported |
| Operating Mode | Continuous operation |
Physical Specifications
| Parameter | Specification |
|---|---|
| Scanner Dimensions | Approx. 89 × 114 × 346 mm |
| Weight | Approx. 1.25 kg |
| Design | Ergonomic handheld design |
| Mounting Options | Handheld / optional stand |
Environmental Conditions
| Condition | Specification |
|---|---|
| Operating Temperature | 5°C – 40°C |
| Operating Humidity | Non-condensing |
| Operating Environment | Office, studio, light industrial |
