Product details
Cynosure Apogee Elite Plus 2020 Dual Wavelength Laser System
Cynosure Apogee Elite Plus 2020 is a professional dual-wavelength laser platform designed for effective hair removal and pigmented lesion treatments. Built for medical aesthetic clinics, the system combines performance, precision, and flexibility to deliver consistent clinical outcomes across a wide range of skin and hair types.
Overview of Cynosure Apogee Elite Plus 2020
Cynosure developed Apogee Elite Plus 2020 to meet the demands of high-volume aesthetic practices. The platform integrates two proven laser wavelengths into a single system, allowing practitioners to customize treatments based on individual patient needs while maintaining safety and efficiency.
Dual Wavelength Laser Technology
Apogee Elite Plus 2020 utilizes Alexandrite and Nd:YAG wavelengths to address different hair colors and skin tones. This dual-wavelength approach enhances treatment versatility and expands the range of clinical applications within one device.
Key Benefits of Apogee Elite Plus 2020
The system supports reliable treatment results through stable energy delivery and advanced pulse control. Clinics benefit from improved treatment speed, predictable outcomes, and enhanced patient satisfaction.
Precision and Consistent Energy Output
Cynosure Apogee Elite Plus 2020 delivers uniform laser energy to target hair follicles effectively. Consistent output helps optimize treatment efficacy while minimizing the risk of uneven results.
Treatment Applications
Apogee Elite Plus 2020 is widely used for laser hair removal and the treatment of benign pigmented lesions. The system allows practitioners to tailor parameters based on treatment area, hair thickness, and skin type.
Hair Removal Across Multiple Skin Types
The platform supports safe and effective hair removal on lighter and darker skin tones. Adjustable settings provide flexibility for treating fine or coarse hair on various body areas.
Patient Comfort and Safety Features
Cynosure engineered Apogee Elite Plus 2020 with integrated cooling technology to enhance patient comfort. This design supports safer treatments while reducing discomfort during laser delivery.
Advanced Cooling Integration
The cooling system helps protect the epidermis by maintaining optimal skin temperature during treatment. This feature allows the use of higher energy levels with improved patient tolerance.
Clinical Workflow and Usability
Apogee Elite Plus 2020 features an intuitive interface that supports efficient daily operation. Practitioners can quickly select treatment parameters and transition smoothly between procedures.
Designed for High-Performance Clinics
The system supports fast treatment sessions and consistent operation, making it suitable for busy clinics that require reliable laser performance.
Why Choose Cynosure Apogee Elite Plus 2020
Clinics that choose Apogee Elite Plus 2020 gain access to a versatile laser platform that combines advanced technology with proven clinical reliability. The system supports long-term practice growth by expanding treatment offerings and improving workflow efficiency.
A Trusted Laser Solution in Aesthetic Medicine
Cynosure Apogee Elite Plus 2020 remains a strong choice for professionals seeking precision, flexibility, and consistent results in laser hair removal treatments.
Cynosure Apogee Elite Plus 2020 Dual Wavelength Laser System
Laser System Overview
Cynosure Apogee Elite Plus 2020 is a dual-wavelength aesthetic laser platform that integrates a 755 nm Alexandrite laser with a 1064 nm Nd:YAG laser in a single system. This combination expands clinical versatility for a range of aesthetic procedures including hair removal, pigmented lesion treatment, vascular lesions, and skin rejuvenation.
Wavelengths and Laser Types
The system operates using two proven laser wavelengths.
The Alexandrite laser at 755 nm effectively targets melanin for high-efficacy hair removal and pigment treatment on lighter skin tones.
The Nd:YAG laser at 1064 nm penetrates deeper tissue and is suitable for darker skin types, vascular lesions, and deeper hair follicles.
Pulse Width and Duration Control
Apogee Elite Plus allows adjustable pulse durations to suit different treatment needs.
For the Alexandrite laser, the pulse width can be adjusted from 0.5 to 300 milliseconds.
For the Nd:YAG laser, pulse durations are adjustable from 0.5 to 300 milliseconds as well, allowing precise energy control during treatment.
Fluence (Energy Density) by Spot Size
The system delivers varying energy levels depending on the selected spot size: for the Alexandrite wavelength, maximum fluence values include approximately 20 J/cm² at 18 mm, 30 J/cm² at 15 mm, and up to 60 J/cm² at 7 mm.
For the Nd:YAG wavelength, fluence scales higher with smaller spot sizes, including 24 J/cm² at 18 mm, 35 J/cm² at 15 mm, 160 J/cm² at 7 mm, and up to 300 J/cm² at 3 mm.
Spot Size Options
Cynosure Apogee Elite Plus supports multiple spot sizes for tailored treatment approaches. Typical sizes range from 3 mm up to 18 mm in diameter, enabling both broad coverage for larger body areas and precise targeting for smaller or sensitive zones.
Repetition Rate (Rep Rate)
The laser system supports high repetition rates to maintain efficient treatment times:
The Alexandrite laser can operate up to approximately 3 Hz, and the Nd:YAG laser can reach up to around 5 Hz, depending on parameter settings chosen by the clinician.
Targeting and Aiming Beam
The system uses an integrated red aiming beam to assist practitioners in accurately positioning the laser handpiece on the treatment area.
Cooling System
Cynosure Apogee Elite Plus is compatible with advanced cooling technologies, including optional air or integrated cooling modules. These cooling systems help maintain comfortable skin surface temperatures during treatment, improving patient comfort and safety.
User Interface and Controls
The system provides an intuitive interface that allows clinicians to adjust parameters such as wavelength selection, fluence, pulse duration, repetition rate, and spot size. This flexibility supports personalized treatment protocols.
Clinical Applications
Cynosure Apogee Elite Plus is indicated for a variety of aesthetic treatments, including but not limited to laser hair removal, pigment correction, treatment of benign vascular lesions, age spots and sunspots, and certain modalities of skin rejuvenation.
Safety and Comfort Features
The platform integrates safety mechanisms and compatible cooling technologies to help minimize thermal discomfort and risk during laser procedures. Adjustable settings support safe operation across multiple skin phototypes.
Physical Dimensions and Requirements
While specific dimensions may vary based on configuration and cooling add-ons, the Apogee Elite Plus system typically occupies a clinical-ready footprint similar to advanced aesthetic laser workstations and requires dedicated medical power supply (230 V, 50/60 Hz, 30 A typical).
