FARO Focus 3D S120 Laser Scanner
Overview of FARO Focus 3D S120
The FARO Focus 3D S120 is a professional terrestrial laser scanner designed to capture accurate 3D data for small to medium-scale environments. Known for its reliability and ease of use, this scanner supports precise documentation, measurement, and analysis across various industries.
With its compact design and proven scanning technology, the FARO Focus 3D S120 remains a trusted solution for professionals who require dependable 3D scanning performance.
What Is FARO Focus 3D S120 Used For
3D Site Documentation
The scanner is widely used to document indoor and outdoor environments, producing detailed point clouds for visualization and measurement.
Accurate Spatial Measurement
FARO Focus 3D S120 enables professionals to perform accurate distance and dimensional measurements, supporting planning and verification workflows.
Key Features of FARO Focus 3D S120
Long-Range Laser Scanning
FARO Focus 3D S120 is capable of capturing detailed scan data over extended distances, making it suitable for architectural and engineering applications.
High Measurement Accuracy
The system delivers reliable accuracy for professional documentation, ensuring consistent results across different project types.
Integrated Color Camera
An onboard color camera captures photographic data, allowing realistic colorized point clouds and enhanced visual context.
Portable and Compact Design
The lightweight and compact form factor allows easy transport and quick setup on-site, improving workflow efficiency.
Benefits of FARO Focus 3D S120
Efficient Field Operations
Fast scan times help reduce on-site work, allowing teams to capture complete datasets in less time.
Reliable and Consistent Results
The scanner produces stable and repeatable measurements, supporting high-quality deliverables for professional projects.
Easy Data Processing
FARO Focus 3D S120 integrates with FARO software solutions, simplifying point cloud processing and data management.
FARO Focus 3D S120 in Professional Applications
Architecture and Construction
Used for as-built documentation, renovation planning, and construction progress monitoring.
Engineering and Industrial Inspection
Supports dimensional analysis, facility documentation, and industrial planning tasks.
Forensics and Public Safety
Helps capture accurate 3D records of accident scenes and investigation sites.
Surveying and Mapping
Provides reliable data capture for short to mid-range surveying and mapping projects.
Why Choose FARO Focus 3D S120
Proven Laser Scanning Technology
FARO Focus 3D S120 is built on well-established scanning technology trusted by professionals worldwide.
Balanced Performance and Portability
It offers an effective balance between scanning range, accuracy, and portability.
Cost-Effective 3D Scanning Solution
Ideal for organizations seeking professional laser scanning capabilities without excessive complexity.
Specifications
Ranging Unit & Measurement
| Feature | Specification |
|---|---|
| Unambiguity Interval | 153.49 m (503.58 ft) |
| Measurement Range | 0.6 m – 120 m (indoor/outdoor, low ambient light with 90% reflectivity) |
| Measurement Speed (Points/Sec) | 122,000 / 244,000 / 488,000 / 976,000 |
| Ranging Error | ±2 mm at 10 m and 25 m (90% + 10% reflectivity) |
| Ranging Noise (Raw / Compressed) | @10 m: 0.6 mm (90%) / 1.2 mm (10%); compressed: 0.3 mm (90%) / 0.6 mm (10%). @25 m: 0.95 mm (90%) / 2.2 mm (10%); compressed: 0.5 mm (90%) / 1.1 mm (10%) |
Color & Imaging Unit
| Feature | Specification |
|---|---|
| Color Resolution | Up to 70 megapixels |
| Dynamic Color Feature | Automatic brightness adaptation |
Multi-Sensor & Orientation
| Sensor | Function |
|---|---|
| Dual Axis Compensator | Levels each scan with accuracy ±0.015° and range ±5° |
| Height Sensor (Barometer) | Detects vertical position relative to fixed point and adds to scan |
| Electronic Compass | Provides orientation to each scan with built-in calibration |
Deflection Unit & Scan Geometry
| Feature | Specification |
|---|---|
| Vertical Field of View | 305° |
| Horizontal Field of View | 360° |
| Vertical Step Size | 0.009° / 40,960 3D pixels on 360° |
| Horizontal Step Size | 0.009° / 40,960 3D pixels on 360° |
| Max Vertical Scan Speed | 5,820 rpm (97 Hz) |
Laser & Optical
| Feature | Specification |
|---|---|
| Laser Power | 20 mW (Class 3R) |
| Wavelength | 905 nm |
| Beam Divergence | 0.19 mrad (0.011°) typical |
| Beam Diameter at Exit | 3.0 mm (circular) |
Data Handling & Control
| Feature | Specification |
|---|---|
| Data Storage | SD / SDHC / SDXC card support (32 GB included) |
| Scanner Control | Touchscreen display with intuitive interface |
| Wi-Fi (WLAN) Access | Remote scanning control, visualization & download via mobile devices |
Power & Hardware
| Specification | Detail |
|---|---|
| Power Supply Voltage | 19 V external / 14.4 V internal battery |
| Power Consumption | 40 W – 80 W (while charging) |
| Battery Life | Up to 5 hours |
| Ambient Temperature | 5 °C – 40 °C |
| Humidity | Non-condensing |
| Maintenance Calibration | Annual |
Physical Dimensions & Weight
| Feature | Specification |
|---|---|
| Dimensions (L × W × H) | 240 × 200 × 100 mm |
| Weight | 5.0 kg |
| Parallax-Free | Yes |
