Thermo Scientific Niton XL2 Plus XRF Analyzer for Reliable Elemental Analysis

Introduction to Thermo Scientific Niton XL2 Plus XRF Analyzer

The Thermo Scientific Niton XL2 Plus XRF Analyzer is a handheld XRF solution designed for fast and accurate elemental analysis in industrial and field environments. This analyzer combines portability durability and analytical performance to support a wide range of material identification and quality control applications.

XRF Technology Overview

What Is X Ray Fluorescence XRF

X Ray Fluorescence is a nondestructive analytical technique that identifies elemental composition by measuring characteristic X rays emitted from a material when it is exposed to an X ray source.

Advantages of XRF Analysis

XRF allows rapid testing without sample preparation chemicals or damage making it suitable for on site inspection and routine screening.

Key Features of Thermo Scientific Niton XL2 Plus

Lightweight Handheld Design

The XL2 Plus features an ergonomic handheld design that enables comfortable extended use in laboratories warehouses and outdoor locations.

Robust and Durable Construction

Built for demanding environments the analyzer is designed to withstand industrial use while maintaining stable performance.

Fast Element Identification

Optimized detection technology delivers elemental composition results within seconds improving workflow efficiency.

User Friendly Interface

The intuitive interface simplifies operation allowing users to perform analysis with minimal training.

Nondestructive Testing

Materials remain intact during analysis supporting safe testing of valuable or critical samples.

Applications of Thermo Scientific Niton XL2 Plus XRF Analyzer

Metal Alloy Identification

Used for rapid identification and verification of metal alloys in manufacturing and recycling operations.

Scrap Metal Sorting

Helps improve sorting accuracy and material value in scrap and recycling facilities.

Quality Control and Inspection

Supports incoming material inspection and quality assurance processes.

Environmental and Compliance Screening

Assists in detecting restricted or hazardous elements for regulatory compliance.

Field Based Material Analysis

Ideal for on site testing where laboratory analysis is not practical.

Benefits for Industrial Users

Increased Productivity

Fast analysis reduces downtime and speeds up decision making.

Cost Effective Operation

Eliminates the need for consumables chemical reagents and external laboratory testing.

Consistent and Repeatable Results

Reliable XRF technology ensures stable measurements across repeated tests.

Enhanced Safety

Non contact analysis reduces exposure to chemicals and minimizes handling risks.

Data Management and Connectivity

Result Storage

Analysis data can be stored directly on the device for later review.

Reporting Capabilities

Supports basic reporting and documentation for inspection records.

Workflow Integration

Designed to integrate easily into existing inspection and quality control processes.

Why Choose Thermo Scientific Niton XL2 Plus XRF Analyzer

The Thermo Scientific Niton XL2 Plus XRF Analyzer offers a balanced combination of portability durability and analytical performance. It is well suited for professionals who require fast reliable elemental analysis across a wide range of industrial applications.

Specifications:

– Analytical Range: Mg-U
– Available Analytical Modes: General Metals, Precious Metals, Coatings, Mining, Soils, Electronic Alloys, Plastics, Industrial Lead in Paint, Lead in Paint Products
– Bluetooth: Supports print functionality, external GPS connectivity and barcode reader
– Camera: Integrated CCD micro camera for locating and recording measurement positions
– Certifications/Compliance: CE, RoHS, FCC, Industry Canada, Safety to IEC 61010-1, UL 61010-1, IP54 (splash and dust proof)
– Data Entry:
* Touchscreen keyboard
* User customizable data entry
* Optional wireless remote barcode reader
– Data Storage:
* 64 MB internal system memory / 128 MB internal user storage
* Stores approximately 10,000 readings with spectra (fewer if images are saved)
– Data Transfer: USB, Bluetooth, RS-232 serial communication
– Dimensions (L x W x H): 10 x 10.8 x 3.9 in (25.6 x 27.5 x 10 cm)

– Libraries:
* Default alloy libraries based on SAE, AISI, ASTM, AA standards
* Users may create and edit libraries
– Operating Environment:
* Temperature: -10°C to 50°C
* Humidity: 0% to 80% relative humidity non-condensing
– Operating System: Proprietary
– Power Consumption:
* 7.4V lithium-ion battery, or 12V DC, 3A, 36W power supply
* Hot swap functionality keeps analyzer powered during battery replacements
– Security Features: Password-protected user security
– Software: Support Software: Niton Data Transfer (NDT) PC software

Analytical Technology

X Ray Fluorescence XRF
Nondestructive elemental analysis
Handheld energy dispersive XRF system

Elemental Range

From magnesium Mg to uranium U depending on model and configuration

Application Capabilities

Metal alloy identification
Material verification
Scrap metal sorting
Quality control inspection
Regulatory and compliance screening
Field based elemental analysis

Detection Performance

Fast elemental identification within seconds
Optimized sensitivity for common industrial alloys
Stable and repeatable measurement results

Analysis Time

Typical analysis time from a few seconds per test
Rapid result display for high throughput inspection

Sample Types

Solid metal parts
Machined components
Scrap metals
Plates bars pipes and sheets
Industrial materials and assemblies

Sample Preparation

No sample preparation required
Direct measurement on solid surfaces
Supports irregular and rough surfaces

User Interface

Integrated color display
Simple menu driven operation
Clear presentation of elemental composition and alloy grade

Software and Data Management

Built in operating software
Onboard data storage
Result review and recall capability
Basic reporting support for inspection records

Connectivity

USB connectivity for data transfer
Supports connection to external devices for reporting and archiving

Power System

Rechargeable lithium ion battery
Designed for extended field operation
Supports continuous daily use

Physical Design

Ergonomic handheld form factor
Lightweight and well balanced design
Rugged industrial housing for demanding environments

Safety Features

Integrated radiation safety controls
Designed to meet XRF safety standards
Secure trigger and measurement control

Operating Environment

Suitable for indoor and outdoor use
Designed to operate in industrial field conditions

Typical Users and Industries

Manufacturing and fabrication
Metal recycling and scrap yards
Quality assurance departments
Inspection and maintenance teams
Environmental and compliance inspectors

Key Advantages

Portable nondestructive elemental analysis
Fast and reliable alloy identification
Reduces reliance on laboratory testing
Improves inspection efficiency and decision making

Package includes:

– Niton XL2 980 Plus
– Locking shielded carrying case
– Two (2) lithium-ion battery packs
– One (1) 110/220 VAC battery charger/ AC adaptor
– Check samples
– Belt holster
– Safety lanyard
– PC connection cables (USB and RS-232)
– Warranty Card- Calibration Certificate

Warranty Information
2 Years
